When storing benzene or other volatile liquids, it’s essential to choose the right type of storage tank to ensure safety, efficiency, and environmental protection. The two most common types of tanks used for volatile liquids like benzene are cone roof tanks and floating roof tanks.

​

benzene is considered a volatile liquid.

Volatility refers to the tendency of a substance to evaporate or vaporize at a given temperature and pressure. Volatile liquids have high vapor pressures and low boiling points, which means they can easily transition from a liquid to a gas (vaporize), even at room temperature.

​

Boiling Point: Benzene has a boiling point of about 80.1°C (176.2°F), which is relatively low compared to many other liquids. This means that at room temperature, a significant portion of benzene can exist in the vapor phase.

​

The vapor pressure of benzene is approximately 13.3 kPa

(kilopascals) at 20°C (68°F).

​

This means that at room temperature (around 20°C), benzene has a relatively high tendency to evaporate into the air, forming vapor. The vapor pressure is an important property when considering the volatility of a substance because it indicates how easily the liquid will transition into a gas phase.

​

Fire Point:

• As mentioned, the fire point of benzene is -4°C (24.8°F), which is just above freezing. This is the temperature at which benzene will continue to burn after being ignited. It's important to note that benzene's fire point is still quite low, reinforcing its flammability hazard.

​

Cone Roof Tanks

​

Advantages:

• Simple and Cost-Effective: Cone roof tanks are generally simpler and cheaper to build than floating roof tanks.

• Better for Low-Volume Storage: Cone roof tanks are often used for smaller to medium-volume storage needs.

• Robust for Stable Conditions: Cone roof tanks work well for liquids with moderate volatility (like benzene, although it requires some level of vapor control).

​

Disadvantages:

• Higher Evaporation Loss: Since the roof is fixed and does not move, the vapor space increases as the liquid level decreases, leading to more evaporative losses.

• No Floating Mechanism: There is no floating roof to minimize the vapor space, so benzene vapors may accumulate above the liquid.

​

Floating Roof Tanks

​

Advantages:

• Reduced Evaporative Losses: Since the floating roof moves with the liquid level, the vapor space above the liquid is minimized, reducing the amount of evaporative loss.

• Lower Emissions: Floating roofs significantly lower the emissions of volatile organic compounds (VOCs), which is particularly important for hazardous substances like benzene.

• Safer for Volatile Liquids: Floating roof tanks are more suitable for the storage of highly volatile liquids, including chemicals like benzene, as they provide better control over vapor space.

​

Disadvantages:

• Higher Initial Costs: Floating roof tanks are more expensive to construct and maintain due to the complexity of the design and materials used.

• Maintenance: Regular maintenance and inspections are required to ensure that the floating roof is functioning correctly and not damaged by corrosion or other factors.

• Less Suitable for Small Storage: Floating roof tanks are typically used for larger volumes of storage because of their cost and complexity.

​

Cost vs. Performance Trade-Off:

​

• Cone Roof Tanks are cheaper and simpler to construct than floating roof tanks. However, the cost-efficiency of a cone roof tank comes at the expense of higher evaporative losses and emissions, which may not be acceptable when storing volatile liquids like benzene. The higher operating and environmental compliance costs associated with these emissions may make a floating roof tank a better long-term investment.

​

• Although floating roof tanks are more expensive, their superior performance in minimizing evaporative losses and reducing emissions makes them a more suitable choice for storing benzene in compliance with safety and environmental regulations

​

Conclusion:

• Cone Roof Tanks are more cost-effective and simpler but are less efficient at minimizing evaporative losses, which can lead to higher emissions of benzene vapors. They are suitable for low- to medium-volume storage of volatile liquids but may not be ideal for volatile liquids like benzene in large volumes.

​

• Floating Roof Tanks, on the other hand, are designed for more volatile liquids, offering much better control of evaporative losses and emissions. They are more expensive but are the better choice when dealing with large quantities of benzene or when environmental and safety regulations are stricter.

​

Storing volatile liquids in cone roof tanks is technically possible, but due to  high volatility and flammability, several safety precautions must be taken to minimize the risks associated with its storage following

​

Vapor Recovery Systems: Since cone roof tanks allow for more vapor space and greater potential for evaporative losses compared to floating roof tanks, it's crucial to install an efficient vapor recovery system to capture and condense the benzene vapors. This prevents benzene vapor from escaping into the atmosphere and reduces the risk of fire or explosion.

​

Pressure Relief/Vent Systems: These systems ensure that the tank does not build up excessive pressure due to vapor expansion or thermal changes. It is important to design and maintain pressure relief valves, vents, and flame arrestors to prevent over-pressurization and minimize the release of flammable vapors.

​

Install flame arrestors on all vents to prevent the ignition of vapors in the event of a spark or flame near the tank. This is especially critical when storing flammable liquids like benzene.

Flame arrestors allow vapors to be vented safely without the risk of combustion.

​

Inerting gas such as nitrogen the tank involves displacing the oxygen inside the tank with an inert gas such as nitrogen. This is particularly important if the tank is to be opened for maintenance or if there is a risk of flammable vapors accumulating. Inerting reduces the likelihood of explosion in the presence of a spark or ignition source.

​

Firefighting and Emergency Response Plans: Fire Extinguishers: Install suitable fire extinguishers (such as Class B for flammable liquids) in areas surrounding the tank and ensure that they are regularly checked and maintained.

​

Emergency Response Plans: Establish and regularly test an emergency response plan for dealing with benzene leaks, spills, or fires. This should include evacuation routes, firefighting protocols, and spill containment procedures.

​

Corrosion Protection: Tank Coatings: Apply appropriate corrosion-resistant coatings to the interior and exterior of the tank to prevent the degradation of the tank structure, especially in areas where benzene vapors may condense and lead to rusting.

​

Tank Sizing and Overfill Prevention: Ensure that the tank has sufficient capacity to prevent overfilling, which could result in spills or leaks. Install high-level alarms and automatic shutoff valves to alert operators and stop the filling process when the tank reaches a predetermined level.

​

Personnel Training and Safety: Employee Training: Ensure that personnel working with benzene or around the storage tank are well-trained in the specific risks of benzene exposure (e.g., through inhalation), emergency procedures, and safe handling practices.

​

​

​

​
